DHDVR0404 LF-AE

DHDVR0404 LF-AE

Quick Overview

> Up to 4/8/16/16 cameras with 1080p realtime preview

> H.264 dual-stream video compression

> DH-DVR0404LF-A: Full channel 2CIF or 2ch@D1+2ch@CIF

> DH-DVR0804LF-A: Full channel 2CIF or 2ch@D1+6ch@CIF

> DH-DVR1604LF-A/1604LF-AE: Full channel CIF or 1ch@D1+15ch@CIF

> HDMI / VGA / TV simultaneous video output > All channel synchronous realtime playback, GRID      interface & smart search

> 3D intelligent positioning with Dahua PTZ dome camera

> Support 1 SATA HDD up to 4TB, 2 USB2.0

> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS

Ukuran     375mm285mm50mm
Stok     100 buah
Berat     1500 gram

Rp 2.000.000 Rp 1.700.000 PPN

Product Description

201205331067981-2

Model DH-DVR0404LF-A DH-DVR0804LF-A DH-DVR1604LF-A DH-DVR1604LF-AE
System
Main Processor Embedded processor
Operating System Embedded LINUX
Video
Input 4channel, BNC 8channel, BNC 16channel, BNC 16channel, BNC
Standard NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
Audio
Input 4channel, BNC 8channel, BNC 4channel, BNC 16channel, BNC
Output 1 channel, BNC
Two-way Talk Same with audio input channel 1
Display
Interface 1 HDMI, 1 VGA, 1 TV, BNC
Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 1/4 1/4/8/9 1/4/8/9/16 1/4/8/9/16
Privacy Masking 4 rectangular zones (each camera)
OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Video/Audio Compression H.264 / G.711
Resolution D1/4CIF(704×576/704×480)/2CIF(704×288/704×240)/CIF(352×288/352×240)/QCIF(176×144/176×120)
Record Rate Main Stream 2CIF(25/30fps)/2ch@D1+2ch@CIF(25/30 fps)/D1(12/15fps) 2CIF(25/30fps)/2ch@D1+6ch@CIF(25/30 fps)/D1(12/15fps) CIF(25/30fps)/1ch@D1+15ch@CIF(25/30 fps)/D1(6/7fps) CIF(25/30fps)/1ch@D1+15ch@CIF(25/30 fps)/D1(6/7fps)
Extra Stream CIF (352×288/ 352×240); QCIF(176×144/176×120)
Bit Rate 48~4096Kb/s
Record Mode Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval 1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Trigger Events Recording, PTZ movement, Tour, Alarm, Email, FTP, Buzzer & Screen tips
Video Detection Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input 4 channel 8 channel 16 channel 16 channel
Relay Output 1 channel 3 channel
Playback & Backup
Sync Playback 1/4 1/4/9 1/4/9/16 1/4/9/16
Search Mode Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Playback Functions Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode USB Device / Network
Network
Ethernet RJ-45 port (10/100M/1000M)
Network Functions HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, Alarm Server
Max. User Access 20 users
Smart Phone iPhone, iPad, Android, Windows Phone
Storage
Internal HDD 1 SATA ports, up to 4TB
Auxiliary Interface
USB Interface 2 ports (1 Rear), USB2.0
RS232 1 port, For PC communication & Keyboard
RS485 1 port, For PTZ control
General
Power Supply DC 12V / 3.3A
Power Consumption 20W (Exclude HDD)
Working Environment -10°C ~+55°C / 10~90%RH / 86~106kpa
Dimension(W×D×H) 1U, 375mm×285mm×50mm
Weight 1.5~2.5kg KG(Without HDD)
